Select All	Heat deflection temperature (0.45Mpa)	Heat distortion temperature (1.8Mpa)	Short-term maximum temperature	Continuous use temperature	Thermal conductivity	Coefficients of linear expansion	Combustion
ABS	98	80	95	65	0.16	9.22	HB
PVC	75	75	70	60	0.165	7	HB
CPVC	60	90	100	90	0.145	5.98	HB
HPVC	60	60.66	80	61/-40	0.1888	.654	HB
PU	110	80	90	70	0.566	6.11
LDPE	45	40	80	65.5	0.36542	11.4442	HB
HDPE	80	85	100	83/-49	0.55	14.06	HB
UPE	85	85	100	85	0.41	19.9	HB
UPE-Oil	80	80	100	75	60	19.9	HB
PP-H	105	80	105	90	0.11	7.75	HB
PP-GF30	156	140		120	0.28	8	HB
PMMA	85	90	80	83/-40	0.1443	6.22	HB
PC1000	140	140	150	117/-151	0.21	6.88	V-2/HB
PC	141	141	136	117/-150	4.6	7.0	V-0
PC-GF20	149	145	133	130	0.20	2.6	V-1
PC-GF30	146	140	142	118	0.27	5	V-1
POM-C	158	158	120	90/-50	0.234	8.47	HB
POM-C-GF30	95	160	140	90/-50	60	2.6	HB
POM-C-OIL	150	95	150	90/-50	80	14	HB
POM-C-CF		160	162
POM-H(Delrin)	170	124	150	86	0.38	12.22	HB
POM-H-GF20	166	128	148	86		5.86	HB
POM-H-PTFE		119	146	83		10	HB
Nylon 6	205-219	205-219	160	92/-30	0.23	7.3	HB
MC-Graphite Powder	190	92	150	92		7.4
MC-MOS2	189	92	148	95/-20		7.3
MC-MOS2-Oil		95	164	94		8.2	HB
MC-Oil	176	90	165	106/-20	0.22	7.3	HB
MC-Lube		95	152	95		9.8
MC703	186	94		92		8.9	HB
MC901	222	94	160	120	0.25	9.0	HB
MC907		95		95	0.23	8	HB
PA6 NYLON	189	73	220	85/70	0.22	9	HB
PA6-GF30	222	212	180	100	0.26	2.7	HB
PA6-MOS2			170	100		9.6	HB
PA66	234	95	150	100	0.25	95	V-2
PA66-GF30	255	251	240	111	0.25	4	HB
PA66-MOS2(GS)	244	91	180	111	0.24	7.3	HB
PTFE	260	80	317-327	180~270	5.9	11.8	V-0
PTFE(Etched)	142	55	285	180~270	0.25	11.8	V-0
PTFE-CF25			320	260/-240	0.74	14.6
PTFE-GF			320	260/-240	0.44	9.8
PTFE-MOS2	142	54	316	260	0.24	11.8	V-0
PTFE-Graphite	142	54	316	260	0.24	11.8	V-0
PTFE-RYT			314	260	0.41	9.9
PBN		78	149	88		7.4-9.5	HB
PVDF (2F)	160	160	160	160	0.20	10E-5	V-0
Rulon-LR	280	280	278	258/-240	0.35	9.19	V-O
Rulon-J				286/-240	0.25	10.44	V-0
Rulon-AR				286/-240	0.34	8.83	V-0
Rulon-641			282	258/-240	0.37		V-0
PETP	166	80	158	116	0.30	7	HB
PETP			158	116		7	HB
PBT(PBT-P)	155	94	223	106	0.22	8.34	HB
PBT-GF30	155	94	148	104	0.22	8.34	HB
PPE(PPO)	136	124	205	105-50	0.18	5.93	HB
PPE(PPO)-GF30	138	132	205	111/-50	0.24	2.52	V-1
PSU1000	180	173	180	150	0.25	5.57	HB
PPSU	213	208	210	180	0.34	5.57	V-0
PES	215	205	200	180	0.17	5.6	V-0
ULTEM-PEI	211	200	200	170	0.11	5.59	V-0
PEI-MT	211	200	192	170	0.11	5.59	V-0
PEI-GF30	211	211	204	180	0.23	1.97	V-0
PMP(TPX)		170	212	198	0.42	12.95	HB
PPS-1000	205	113	258	222	0.21	2.5	V-0
PPS-GF40		258	258	222	0.21	1.6	V-2
PPS-PVX(HPV)		114	260	220			V-0
PEEK	210	141	310	250	0.25	4.68	V-0
PEEK-CF30		315	287	258	0.91	1.43	V-0
PEEK-GF30	342	315	310	250	0.42	2.15	V-0
PEEK-PVX(HPV)	292	276	310	250	0.23	2.3	V-0
PEEK-MT(醫療級)	183	140	300	258	0.24	5	V-0
PEEK-TF(PTFE)	292	276	300	258	0.23		V-0
PEEK-Ceramic	260	220	300	258	0.44	4.5	V-0(1.5mm)
Torlon PAI-4203	280	277	270	250	0.28	3.2	V-0
Torlon PAI-4301		280	270	250	0.7	2.4	V-0
Torlon PAI-5530		270	270	250	0.35	3.9	V-0
PBI/PEEK Alloy		300	348	282	0.27		V-0(0.8mm)
PBI		426	540	345	0.3	2.35	V-0
PHENOLIC X PEPER	80	80	182	128	50	1.2	HB
PHENOLIC XPC PEPER			178	132			HB
PHENOLIC XX PEPER			178	132			HB
PHENOLIC XXX PEPER			182	128		1.48	HB
PHENOLIC C			180	124	0.37	2.15	HB
PHENOLIC CE			180	124	0.37	2.06	HB
PHENOLIC L			180	124		1.7	HB
PHENOLIC LE			180	126		1.8	HB
FRP	310	380	230	180~200			V-0
3K	310	300	180~200	230			V-0
MICA (MUSCOVITE)			952	652	0.2	7	V-0
MICA (SILICONE RESIN)	550	560	700	1000	0.2	7	V-0
MICA (EPOXY RESIN)			700	1000	0.2	7	V-0
Starlint			391	262	0.23	6.7
Machinable Glass Ceramic			1000	800	1.48	1.02
AL2O3	1500	1500	1450	1200	22.5	3641	222
ZRO2	1800	2500	1900	1600	2.3
MGO.SIO2			1100	900	3.4	6.5～7.5
ABS-SD	87	70	100	70			HB
PVC-CN	80	85	80	60/-15	0.15	7	V-0
PVC-SD			80	60/-15	0.15	5	V-0
UPE-SD			94	81		19.7
PP-CN			93	90/5			HB
PMMA-SD	94		136	115/-40	0.18	6	HB
PC-SD	138	127	134	115/-150	0.22	6.6	HB
POM-CN		81	140	90/-50		7	HB
POM-AS	130	87	140	90/-50	0.32	11.8	HB
MC501-R2	181			120/-30	0.52	9
MC501-R6	181		180	120/-30	0.72	7.6
PPS-CN		174	165	95		9.0	HB
PPS-SD		167	258	222			V-0
PEEK-CN			300	258	0.28	1.6	V-0
Torlon PAI-SD		282	258	252	0.53	1.43-2.3	V-0
Torlon PAI-CN		282	258	252		1.4	V-0
PI-CN		382	450	258		2.9	V-0
Esd225(POM)		106	140	90		16.73	HB
Esd410(C)(Ultem PEI)		211	200	170	0.36	3.23	V-0
Esd420(Ultem PEI)		217	220	170	0.21	3.6	V-0
Esd480(PEEK)		262	300	245	0.24	3.2
Esd500HR(PTFE+MICA)		100	280	260		10.25	V-0
Esd520HR(PAI)		270	270	250	0.35	4.24	V-0
F884-CN(導電玻纖)			222	134			V-0
F885-SD			222	134			V-0
CFRP4			2200	20~2000
CAS761	300	300	360	300	0.3	10	V0
CAG762	250	250	360	300	0.3	10	VO
CCR766			360	300	0.3	10
ISOLA CDM	300	300	360	300	0.3	10	VO
